Chucks MPC - Mini Precision
MPC11C-HSK-E50-A=100
| A | 100 mm |
| D = Wrench Ø | 16 mm |
| max. 1/min | 30000 1/min |
| E | 50 mm |
| D1 | 24,5 mm |
| a | 4,5° Grad |
| L1 | 70 mm |
| L2 | 19 mm |
| L3 | 20 mm |
| G | M8x1 |
Note: May include deviations
Chucks MPC - Mini Precision
MPC11C-HSK-E50-A=100
- Order number: 61351331005
- EAN-NR: 61351331005
- conical
- high runout accuracy
- high speed cutting
- very slim
Quantity:
Availability:
Immediately
~ 5 working days
3 weeks
4 weeks
5 weeks
6 weeks
On request
Prices plus VAT plus shipping costs
TECHNICAL DATA
MPC11C-HSK-E50-A=100
| A | 100 mm |
| D = Wrench Ø | 16 mm |
| max. 1/min | 30000 1/min |
| E | 50 mm |
| D1 | 24,5 mm |
| a | 4,5° Grad |
| L1 | 70 mm |
| L2 | 19 mm |
| L3 | 20 mm |
| G | M8x1 |
TECHNICAL DATA
MPC11C-HSK-E50-A=100
| A | 100 mm |
| D = Wrench Ø | 16 mm |
| max. 1/min | 30000 1/min |
| E | 50 mm |
| D1 | 24,5 mm |
| a | 4,5° Grad |
| L1 | 70 mm |
| L2 | 19 mm |
| L3 | 20 mm |
| G | M8x1 |
